قیر نفوذی
منبع نفوذ برای تامین سطح شن با هدف آسفالت سرد یا گرم استفاده می شود. در این نوع جاده سازی، از یک لایه نازک برای رشد داخل جمجمه ای استفاده می شود تا سطوح پایینی را در برابر آب و هوای مرطوب محافظت کند، سپس بقیه بستر به هم متصل شده و سطح دراز کشیدن سخت تر می شود.
آنالیز قیر نفوذی ۴۰/۵۰
Test Title Result Standard range TEST Method SP gr @25/25 cc 1.04 Min: 1.01 - Max: 1.06 ISIRI 2956 - ASTM D70 Penetration @25c c-100gr-5s 45.7 Min: 1.01 - Max: 1.06 ISIRI 2950 - ASTM D5 Softening Point 53.2 Min: 1.01 - Max: 1.06 ISIRI 3868 - ASTM D36 Solubility in Trichloroethylene (bitumen content) 99.99 Min: 1.01 - Max: --- ISIRI 2953 - ASTM D4 Ductility @25 cc cm >100 Min: 1.01 - Max: --- ISIRI 3866 - ASTM D113 Flash Point cc 319 Min: 1.01 - Max: --- ISIRI 1175 - ASTM D92 Loss On heating w t% 0.03 Min: --- - Max: 0.2 ISIRI 2957 - ASTM D6 Drop Penetration after loss on heat 8.1 Min: --- - Max: 20 ISIRI 2950 - ASTM D6 & D5 Spot Test Negative Negative ISIRI 2949
آنالیز قیر نفوذی ۶۰/۷۰
| Test Title | Result | Standard range | TEST Method |
|---|---|---|---|
| SP gr @25/25 cc | 1.02 | Min: 1.01 - Max: 1.06 | ISIRI 2956 - ASTM D70 |
| Penetration @25c c-100gr-5s | 65.4 | Min: 60 - Max: 70 | ISIRI 2950 - ASTM D5 |
| Softening Point | 49.7 | Min: 49 - Max: 56 | ISIRI 3868 - ASTM D36 |
| Solubility in Trichloroethylene (bitumen content) | 99.99 | Min: 99.5 - Max: --- | ISIRI 2953 - ASTM D4 |
| Ductility @25 cc cm | >100 | Min: 100 - Max: --- | ISIRI 3866 - ASTM D113 |
| Flash Point cc | 321 | Min: 232 - Max: --- | ISIRI 1175 - ASTM D92 |
| Loss On heating w t% | 20.0 | Min: --- - Max: 0.2 | ISIRI 2957 - ASTM D6 |
| Drop Penetration after loss on heat | 38. | Min: --- - Max: 20 | ISIRI 2950 - ASTM D6 & D5 |
| Spot Test | Negative | Negative | ISIRI 2949 |
آنالیز قیر نفوذی ۸۵/۱۰۰
Test Title Result Standard range TEST Method SP gr @25/25 cc 1.02 Min: 1.01 - Max: 1.06 ISIRI 2956 - ASTM D70 Penetration @25c c-100gr-5s 91.2 Min: 85 - Max: 100 ISIRI 2950 - ASTM D5 Softening Point 45.9 Min: 45 - Max: 0 ISIRI 3868 - ASTM D36 Solubility in Trichloroethylene (bitumen content) 99.98 Min: --- - Max: --- ISIRI 2953 - ASTM D4 Ductility @25 cc cm >100 Min: 100 - Max: --- ISIRI 3866 - ASTM D113 Flash Point cc 322 Min: 232 - Max: --- ISIRI 1175 - ASTM D92 Loss On heating w t% 0.03 Min: --- - Max: 0.2 ISIRI 2957 - ASTM D6 Drop Penetration after loss on heat 8.1 Min: --- - Max: 20 ISIRI 2950 - ASTM D6 & D5 Spot Test Negative Negative ISIRI 2949
آنالیز قیر نفوذی ۱۲۰/۱۵۰
| Test Title | Result | Standard range | TEST Method |
|---|---|---|---|
| SP gr @25/25 cc | 1.013 | Min: 1.01 - Max: 1.06 | ISIRI 2956 - ASTM D70 |
| Penetration @25c c-100gr-5s | 132.0 | Min: 120 - Max: 150 | ISIRI 2950 - ASTM D5 |
| Softening Point | 42 | Min:38 - Max: 0 | ISIRI 3868 - ASTM D36 |
| Solubility in Trichloroethylene (bitumen content) | 99.99 | Min: --- - Max: --- | ISIRI 2953 - ASTM D4 |
| Ductility @25 cc cm | >100 | Min: 100 - Max: --- | ISIRI 3866 - ASTM D113 |
| Flash Point cc | 323 | Min: 232 - Max: --- | ISIRI 1175 - ASTM D92 |
| Loss On heating w t% | 0.03 | Min: --- - Max: 0.2 | ISIRI 2957 - ASTM D6 |
| Drop Penetration after loss on heat | 8.3 | Min: --- - Max: 20 | ISIRI 2950 - ASTM D6 & D5 |
| Spot Test | Negative | Negative | ISIRI 2949 |
آنالیز قیر نفوذی ۲۰۰/۳۰۰
| Test Title | Result | Standard range | TEST Method |
|---|---|---|---|
| SP gr @25/25 cc | 1.011 | Min: 1.01 - Max: 1.06 | ISIRI 2956 - ASTM D70 |
| Penetration @25c c-100gr-5s | 250.0 | Min: 200 - Max: 300 | ISIRI 2950 - ASTM D5 |
| Softening Point | 38 | Min:35 - Max: 40 | ISIRI 3868 - ASTM D36 |
| Solubility in Trichloroethylene (bitumen content) | 99.98 | Min: --- - Max: --- | ISIRI 2953 - ASTM D4 |
| Ductility @25 cc cm | >100 | Min: 100 - Max: --- | ISIRI 3866 - ASTM D113 |
| Flash Point cc | 325 | Min: 232 - Max: --- | ISIRI 1175 - ASTM D92 |
| Loss On heating w t% | 0.04 | Min: --- - Max: 0.2 | ISIRI 2957 - ASTM D6 |
| Drop Penetration after loss on heat | 8.2 | Min: --- - Max: 20 | ISIRI 2950 - ASTM D6 & D5 |
| Spot Test | Negative | Negative | ISIRI 2949 |
